KOOTRAC

Details

Our new Kootrac 3000 Series design is a reimagining of the classic high speed tracked vehicle we have all grown to love. This model has the agility required to maneuver tight and unfavorable environments, combined with its electric controls, allows for high precision. The foreword mounting of the cab allows us to take advantage of the increased visibility. Having the engine compartment in the center of the machine allows for easy servicing and maintenance.

With our specialized unique carrier, the possibilities are limitless. If you have a job that needs to be done, whether on steep slopes or wet, uneven terrain, we either have a machine to fit your needs or WE WILL Custom BUILD.

  • Maximum Payload: 35,000 lbs (15,783 kg)
  • Maximum Weight on Vehicle: 28,000lbs (12700kg)
  • Gross Vehicle Weight: 39,260lbs (17808kg)
  • John Deere Engine (6.8L -250HP)
  • MAIN HYDRAULIC PUMPS: Sauer-Danfoss 90 Series Axial Piston Variable Displacement Pumps c/w Electronic Controllers (100 cc displacement)
  • Poclain High Torque/Low Speed (HTLS) Motors, 233 cu in. displacement Two speed c/w Integral Fail Safe Brake
  • HYDRAULIC PUMP DRIVE: Funk Three Pad Pump Drive
  • HYDRAULIC OIL COOLERS: Custom Design for Extra Cooling Capacity (J D Radiator)
  • DanFoss Electronic Joystick c/w multiple Electronic Functions
  • Danfoss Electronic Control Module Model DP600 Dual Axis Implement Controls
  • ROPS/FOPS/OPS certified
  • Fully Enclosed And Hydraulically Tilting
  • Air Conditioner/Heater
  • Torsion bar suspension
  • Pre-stressed, Heat Treated Torsion Bars
  • Solid Mounted Anchors
  • Forged Road Arms
  • Cast Steel Reinforced Roadwheels & Idler Wheels
  • Spoke Type Sprocket Carrier c/w Track Guide Slot
  • Work Hardening In-Pitch Sprockets
  • Cast Steel Manganese Alloy Track Pads
  • Hardened Track Pin & Nuts
  • Natural Rubber Track Bushings
  • 5 Sets Dual Roadwheels per side 23” (610mm) Diameter
  • Track Shoe Width – 22” (559mm)
  • 12 Volt
  • Alternator – 130 amp
  • Starter – 12 Volt
  • Single Batteries – 1400 cca each

  • DanFoss 45 Series Pump – 75cc
  • Proportional Valve with Electronic Actuators
  • Light Kit
  • LED Light System

Forest service approved

Dry Type c/w Pre-Cleaner

  • Computer Monitored Digital Gauges/Indicators
  • Includes Tachometer, Hour Meter, Volt Meter, Fuel/Water Temperature, Engine Oil Pressure, Hydraulic Oil Temperature
  • Air Filter – Restriction Indicator
  • Rear Cameras
  • Grapple Cameras
  • Arch Grapple
  • Drill Rig
  • Crane

And much more!

WE WILL CUSTOM BUILD TO SUIT YOUR NEEDS

With our specialized unique carrier, the possibilities are limitless. If you have a job that needs to be done, whether on steep slopes or wet, uneven terrain, we either have a machine to fit your needs or WE WILL Custom build.
